Machine working weight (kg) | 20930 |
Bucket capacity (m³) | 1 |
Boom Length (mm) | 5700 |
Bucket rod Length (mm) | 2900 |
Country of origin | Xuzhou |
Tonnage (ton) | 20 |
power | Traditional power |
bucket | backhoe |
vendor | import |
power | Traditional power |
performance | |
Rotational speed (RPM) | 11.5 |
Walking speed (km/h) | 3.5/5.7 |
Climbing ability (%) | 70/35° |
Specific grounding pressure (Kpa) | 6 |
Bucket digging force (kN) | 140.1 |
Bucket rod digging force (kN) | 106.4 |
Power system | |
Engine type | CAT C6.4ACERT |
Rated power (kw/ RPM) | 103/2000 |
Displacement (L) | 6.37 |
Number of cylinders (PCS) | 6 |
Cylinder diameter × stroke (mm) | 102×130 |
Cooling way | water-cooling |
The hydraulic system | |
Maximum flow of main pump (L /min) | 205 |
Working hydraulic oil circuit (Mpa) | 35 |
Walking hydraulic circuit (Mpa) | 35 |
Rotary hydraulic circuit (Mpa) | 25 |
Pilot oil circuit (MPa) | 3.9 |
Boom cylinder - Number x Cylinder diameter x stroke (mm) | 2-120×1260 |
Bucket rod cylinder - Number x Cylinder diameter x stroke (mm) | 1-140×1504 |
Bucket cylinder - Number x Cylinder diameter x stroke (mm) | 1-120×1104 |
Hydraulic fracturing pipeline is standard | NO |
Oil capacity | |
The fuel tank (L) | 410 |
Hydraulic tank (L) | 120 |
Hydraulic system (L) | 260 |
Engine oil change (L) | 30 |
Cooling liquid (L) | 25 |
Body size | |
Total length of transport (mm) | 9460 |
Total transport width (mm) | 2800 |
Total transport height (mm) | 3050 |
Full height of cab (mm) | 2950 |
Counterweight ground clearance (mm) | 1020 |
Track grounding length (mm) | 3265 |
Total track length (mm) | 4075 |
Width of track plate (mm) | 600 |
Total track width (mm) | 2800 |
Track gauge (mm) | 2200 |
Minimum ground clearance (mm) | 450 |
Radius of rotation of rear end (mm) | 2750 |
Operating range | |
Maximum excavation radius of stop face (mm) | 9850 |
Maximum excavation depth (mm) | 6710 |
Maximum excavation height (mm) | 9840 |
Maximum unloading height (mm) | 6500 |
Maximum vertical excavation depth (mm) | 6180 |
Maximum effective digging depth (mm) | 6540 |
Width of bulldozing plate × height (mm) | No plow |
Lifting or pushing depth with shovel (mm) | No plow |
