| Model | TT10 |
| Performance parameters | Specification |
| full vehicle height | 2170mm |
| full car length | 2200mm |
| wheelbase | 420mm |
| Standard Bucket Capacity | 0.03m³ |
| Track width | 180mm |
| rated power | 12kw |
| Maximum digging radius | 2900mm |
| Maximum excavation depth | 1650mm |
| Maximum excavation height | 2500mm |
| Maximum unloading height | 1850mm |
| full vehicle width | 940mm |
| Vehicle weight | 1050kg |
| Working device form | backhoe |
| Minimum ground clearance | 385mm |
| Track ground length | 1250mm |
| Chassis width | 920mm |
| Shipping length | 2170mm |
| radius of gyration | 1550mm |
| hydraulic pump | Imported from Japan |
| Multi-way valve | Imported from Italy |
| Model | TTE08 | TTE10 | TTE12 | TTE15 |
| Model | TT08 | TT10 | TT12 | T |
1. Excavators with compact dimensions can easily drive through narrow passages and doors.
2. Retractable undercarriage and dozer blade allow the excavators to be configured for excellent working stability and optimum performance.
3. Powerful engine and perfectly matched hydraulics provide efficient, economical and reliable performance for the toughest of jobs.
4. Bucket hoses are well protected within the boom and the cylinder is mounted above the structure.
5. The operator area is spacious and laid out to provide comfort and ease of operation.
6. Excellent engine provides excellent power with minimal fuel use for more productivity per tank.
