Total weight (KG) | 14.5 | A-Overall length (mm) | 7580 | O-Maximum excavating height(mm) | 8630 |
Bucket capacity(m3) | 0.60-0.75 | B-Overall width (mm) | 2490 | P-Maximum unloading height(mm) | 6180 |
Engine model | CUMMINS QSF3.8 | C-Total height(Swing arm top)(mm) | 2780 | Q-Maximum excavating depth(mm) | 5500 |
Power(kw/r/min) | 86/2200 | D-Total height(Cab roof)(mm) | 2815 | R-Maximum vertical wall excavating depth(mm) | 4940 |
Volume of fuel tank (L) | 247 | E-Counterweight ground clearance (mm) | 870 | T-Maximum excavating distance | 8305 |
Traveling speed (km/h) | 5.3/3.1 | F-Min. ground clearance (mm) | 430 | U-Maximum excavating distance at ground level(mm) | 8180 |
Slew speed (r/min) | 12 | G-Turning radius of vehicle tail(mm) | 2155 | V-Minimum turning radius(mm) | 2495 |
Gradeability(%) | 70 | H-Ground contact length of track(mm) | 3000 | W-Maximum height at minimum turning radius(mm) | 6430 |
Bucket excavating force (KN) ISO | 90 | J-Track shoe length (mm) | 3735 | X-Distance between the center of gyration and the rear end side(mm) | 2155 |
Bucket rod length(m) | 2500 | K-Track gauge(mm) | 2000 | Z-Counterweight height(mm) | 1935 |
Length of swing arm (m) | 4600 | L-Track shoe width (mm) | 2500 | A1-Ground contact length(during transportation)(mm) | 4410 |
Ground pressure(KPa) | 39 | M-Track shoe width(mm) | 500 | ||
Hydraulic oil tank volume (L) | 130 | N-Rotary table width(mm) | 2490 |
